Thermal Spray Gun
Enquire now
Datasheet
Where it is used
Typical process uses for Flame Spray Gun across industrial surface preparation.
Anti-Corrosion Coating is required.
Improvements in Wear Resistance Properties
To reclaim worn-out components and improve electrical conductivity
Coatings with a Thermal Barrier
To garnish equipment made of a variety of materials
What to know
In Flame Spray Gun the flaming wire spray method, the wire alloy is blended in an effervescent O2 and LPG fire. The fuel gas can obtain acetylene, propane, or hydrogen. The wire is fed concentrically into the flame, where it is melted & atomized by the increase of air of compressor that also shows the blended material towards the component exterior.
The Type 12M Gun has a controllable speed range of around 1-1/2 feet of wire per minute with conventional gears to roughly 45 feet per minute with the unique, easy-to-install high-speed gear set. The high-speed gear set is used to spray metals with lower melting points, such as Babbitt, tin, and zinc, at high speeds indefinitely. For portable applications and field repair work, the entire system (excluding the compressor) can be put on a cart
| Air Pressure (psi) | 70 – 100 |
| Nozzle Size (mm) | 3.15 |
| Form | Wire |
| Item Weight (kg) | 15 |
| Paint Color | Blue & Also as per client requirement |
| Air Consumption (cfm) | 8 to 9 |
| Air Inlet (NPT) | 3/8” |
| Warranty | 1 year |
| Packaging Type | Box |
| Finish | SA2.5 |
| Sound pressure (dB) | 115 |
| Material | OEM |
| Minimum Order Quantity | 1 Number |
Flame spraying is a thermal spray coating technology that produces high-quality surface coatings by melting a spray coating material and propelling it onto a substrate using heat generated by the combustion of a fuel gas with oxygen.
Flame spraying is a low-cost option for applying metallic and ceramic coatings in less demanding environments.
The use of flame spraying as a surface treatment allows for the application of a wide range of metallic or ceramic coatings on a wide range of component materials that require good wear resistance and impact resistance.
Micro Blaster, as the surface technology expert in flame spraying, offers a wide range of thermal spray coating materials to meet your individual requirements.
Our facilities produce a wide range of component sizes to demanding standards with reliable, reproducible outcomes, backed by a customer-driven service.
In the flame spray process, a combustible gas serves as the heat source that melts the coating material, which may be in rod, wire, or powder form. Commonly selected gasses include acetylene, propane, methyl-acetylene-propadiene (MAPP) gas, and hydrogen, along with oxygen. Overall, changing the sand blasting nozzle and/or air cap is all that is needed to adapt the gun to different alloys, wire sizes, or gasses.
The flame spray process is widely used for the reclamation of worn or out-of-tolerance parts, frequently with nickel-base alloys. Bronze alloys may be sprayed for some bearings and seal areas. Mixtures of tungsten carbide and nickel-base alloys are used for wear resistance. The zinc spray gun is commonly coated on bridges and other structures for corrosion resistance.
Flame spraying may be utilized for a variety of reasons:
We are a leading manufacturer, supplier of Flame Spray Gun Manufacturer in India. We provide Zinc Coating by Metalizing Gun, It is the same as a thermal spray gun. We also provide sand blasting machine, shot blasting machine, sand blasting cabinet, grit blasting machine, thermal spray gun, zinc spray gun, & abrasive media at a low price.
Enquiry form
Fields marked with * are required.
FAQ
Quick clarity on quotation, supply and what our team needs to size Flame Spray Gun correctly.
Flame Spray Gun is a product in the Micro Blaster range for grit blasting, shot blasting and industrial surface preparation. It is selected based on your process, finish requirement and production volume.
Flame Spray Gun supports surface cleaning, preparation or process efficiency in blasting operations. Tell us your component type and finish target so we can confirm suitability and recommend compatible media or equipment.
Share your application, quantity, finish requirement and delivery city or port. We provide a manufacturer-direct quotation with clear commercial scope for supply, packing and freight.
Yes. Micro Blaster supplies Flame Spray Gun domestically across India and for export shipments, with documentation support for commercial orders. Mention your destination and timeline when enquiring.
Most enquiries receive a reply within one business day during working hours. Include application details, quantity and delivery location for the fastest technical and commercial response.
