Wet Blasting Machine
A wet blasting machine is an industrial procedure that involves applying pressure wet slurry to a surface to achieve different cleaning or finishing effects. Also referred to as a wet abrasive blasting machine. A high-volume pump is particularly designed to combine abrasive material and water. This slurry mixture is then sent to a nozzle (or nozzles), where controlled compressed air is utilized to control the pressure of the slurry as it blasts the surface.
A wet sand blasting machine is employed in an assortment of industrial surface preparation applications, and it is thought to be suitable for die cleaning due to the fluid's short and convoluted route. The system is a closed loop. During the blasting cycle, the water utilized in the process is recirculated within the machine. After the blasting cycle, the machine's effluent runs into a filter. The filtered water is then used to rinse the dies & is pumped to the machine's nozzles. All water remains within the process loop. Make-up water is solely employed to compensate for evaporation.
A wet surface treatment procedure that cleans, descales, & degreases in one step without utilizing chemicals & solvents. A pressured blasting combination of water & abrasive media scrubs the part externals instead of impinging or impacting it, maintaining near tolerance dimensions. The pressure blast process is the ideal approach for preparing metal, plastic, & composite surfaces in an assortment of sectors, including aerospace, plating, electronics, & more.
A wide-nozzle wet blasting equipment was employed to achieve shot peening. First, the effects of particle size & shape on typical parameters such as exterior roughness, residual stress, FWHM, & Vickers hardness were investigated, and observed by fatigue strength testing on peened materials. From robust manually controlled wet blasting equipment to automated & robotic wet-blast systems, no further machine maker has greater options for surface treatment.
Our proprietary slurry pump is at the heart of the wet blasting machine system, while our advanced wet blasting nozzle, steeply sloped slurry hoppers, & field-tested engineered designs all work together to deliver excellent performance & the extraordinary benefits of wet blast external treatment technology. When the machine is idle, the abrasive settles to the bottom of the machine sump. When the pump is actuated, a part of the pump output is sent to a stirrer pad in the sump. The stirrer effectively combines the water & media, ensuring that an adequate mix is established from the start. The remainder of the pump output is sent through a pipe to a blast nozzle.
The abrasive media is mixed with water & pumped as slurry to special blast nozzles. At the nozzle, compressed air is introduced to accelerate the slurry onto the die. The abrasive remains encased by water & flows across the die face & via the bearing, providing thorough & uniform cleaning. The process has been found to be a more gentle cleaning action, compared to traditional dry blasting.
Wet blasting is a solvent & dust-free cleaning process that utilizes an operator-safe mix of water & media a glass beads & aluminium oxide mixture is normally used. This is launched at the die via an evolved blast nozzle. The operating pressure of the process is approvingly controllable, & effluent from the machine is processed via a filtration system, whichever separates out solid waste for safe disposal & permits the water to be recycled.
The wet blasting nozzle system is a simple, low-cost option for high-volume wet abrasive blasting certain may be employed with your existing pressure blast equipment. The machine may be employed with either tap water & rust inhibitors provided by any primary pump. No specialized equipment is required. The wet blasting nozzle system provides the best performance available in wet abrasive blasting technology.
The wet blasting machine system easily handles industrial maintenance applications such as cleaning & releasing coatings of concrete, layer-by-layer paint removal, whole coating removal to a predetermined degree of cleanliness (white metal, for example), or the removal of oxidized layers from steel. The technique is also extremely successful in delicate applications, such as the petrochemical sector, where sparks & static electricity are prohibited. Another benefit to the environment & economics is a 95% decrease in dust when employing wet blasting machine systems. This permits for minimal & no containment, dust collectors, & negative pressure. Furthermore, it provides total & simple access throughout the structure existing cleaned & blasted. There is also no requirement for air-supplied hoods, which improves operator comfort & public impression of the job being done. The added benefit of permitting the operator complete control of the machine at the blast nozzle via remote control allows for fewer personnel.
We are the leading wet blasting machine manufacturer and also the supplier of wet sand blasting machine in India. Micro Blaster also offers an abrasive blasting machine, sand blasting machines, portable shot blasting machines, grit blasting machines, sand blasting safety equipment, shot blasting spare parts, air compressors, dust collectors, granite engraving machine, laser rust cleaning machines, thermal spray gun, mineral powder, abrasive media etc.
