Pressure Blast Cabinet

Pressure Grit Blasting Cabinet

Pressure grit blasting cabinet works on the direct pressure principle of blasting. When high abrasive media velocity produces by pressure grit blaster which results in completing the job at a faster rate. A pressure vessel bolted below a tank of a grit blast cabinet for automatic abrasive refilling arrangements. For the high efficiency of dust collection, a tubular fabric bag dust collector, with a generous filter area is attached with the blaster cabinet as a standard feature. A manual shaker is provided for shaking.

Pressure Grit Blast Cabinet

A high-Pressure grit blaster cabinet is recommended for fast cleaning, removal of corrosion and heavy rust using coarse abrasives. All types of coarse and medium-sized abrasives can be used depending on the application. Realizing a 5 to 10 times higher output (compared to suction feed) direct pressure grit blasting cabinets operate with one hose connected to the blast nozzle.

As a small grit blaster cabinet pressurizes the abrasive equal to the transportation air pressure, the abrasive simply ‘fall’ (by means of gravity) into this air stream and is propelled towards the object. So, In this way, the air compressor is only used for transporting the abrasive (without having to suck it up as well).

Good visibility and effective dust containment are achieved by the powerful dust extracting system which depending on the abrasive material type and application, dust extraction can be optimized by applying automatically cleaned filter cartridges or a cyclone separator.

Pressure Grit Blast Cabinet Standard Models:

• APB-9182
• APB-12090
• APB-150120

Options available on request:

• Higher output blast guns in place of standard.
• ON / OFF fitted with optional accessories.
• Reverse jet cartridge filter dust collectors.
• Foot-operated treadle switches for blasting.
• Motorized bag-shaking arrangement.

Benefits of Pressure Blaster

• Simple setup of pressure blast cabinet and abrasive amount
• Easy start/stop blasting with large foot pedal
• Sufficient access possibilities with large side-door
• Easy disposal of collected dust in sand blasting hopper
• Good practical view through a full-width window and effective dust extraction

Automatic filter cleaning

• Better blasting value
• Adds a nice cosmetic finish
• Optimal surface preparing for further painting- and gluing processing
• Realizing a 55 to 99.99% higher work speed (compared to suction feed)
• Most abrasives can be used (also the ‘heavy ones’ like stainless steel shot or chilled iron grit

Quality includes

• Wear-resistant abrasive metering valve and blasting nozzle
• Not dust or no abrasive pollution of the surrounding work area.
• Durable, powder-coated cabinet and extractor
• The rubber lining protects cabinet- and abrasive from wear

Better pressure blasting cabinet economics

• Affordable pressure blast cabinet for most industrial branches because Gritco’s special mini blast pot can be placed directly under the hopper
• Eliminated production downtime through better pre-treatment

Pressure Blasting Cabinet Manufacturer in India

Blaster are the manufacturer of Pressure Grit Blasting Cabinet (Pressure grit blast cabinet) is a low price in all cities: Delhi, Mumbai, Pune, Rajkot, Kolapur, and all cities. Pressure blasting cabinet for sale area is all south cities in India, Cities are Bangalore, Pune, Coimbatore, Chennai, etc. Pressure blast cabinet from micro blaster automate production sequences and improve the work environment.
